ETEILY Grey color and square shape 698 - 2700MHz 7 /16 DIN Female 2 Way RF Power Splitter
SKU: ET-SP2W-DFS
CE Certified
ROHS
Reach.png)
sales@eteily.com .png)
Call Now: +91-8889017888.png)
REQUEST FOR QUOTE.jpeg)
"We are world Wide Supplier"
Whatsapp Contact +91-9343643799
Grey Color and Square Shape 698 - 2700MHz 7 /16 DIN Female 2 Way RF Power Splitter
What is power splitter? Power splitters (also power splitters and, when used in reverse, power combiners) are passive devices used in the field of radio technology. They couple a defined amount of the electromagnetic power in a transmission line to a port enabling the signal to be used in another circuit.Power dividers are used in a wide variety of applications and can satisfy almost any requirement where a signal needs to be distributed or combined. HTmicrowave offers 2-way,3-way and 4-way configurations fitted with N,7/16 DIN-Female or SMA-Femal connectors at all ports.Indoor or Outdoor use.This RF Splitter Series provide a low loss,same power split at all output ports while maintaining excellent amplitude and phase balance.Mainly used in repeater or base station to split,also can be used in indoor distribution system.Features of our products are high isolation,alternate connector configurations, rack mounting,high power combining and weatherproofing.You can choose the best product solutions for your specific needs here.
| Electrical Specifications: | |||||||||
| Frequency Range | 800-2500MHz | 800-2700MHz | 698-2700MHz | ||||||
| Split Way | 2way | 3way | 4way | 2way | 3way | 4way | 2way | 3way | 4way |
| VSWR | ≤1.25:1 | ≤1.25:1 | ≤1.25:1 | ||||||
| Insertion Loss(dB) | ≤3.3 | ≤5.2 | ≤6.3 | ≤3.3 | ≤5.2 | ≤6.4 | ≤3.3 | ≤5.2 | ≤6.5 |
| In-band Ripple(dB) | ≤0.3 | ≤0.4 | ≤0.5 | ≤0.3 | ≤0.4 | ≤0.5 | ≤0.3 | ≤0.4 | ≤0.5 |
| Average Power(W) | 200/300/500 | 200/300/500 | 200/300/500 | ||||||
| 3rd Order IMD(dBc) | ≤-120/-140/-150@2X43dBm | ≤-120/-140/-150@2X43dBm | ≤-120/-140/-150@2X43dBm | ||||||
| Impedance(Ω) | 50 | 50 | 50 | ||||||
| Connectors Type | D-Female | D-Female | D-Female | ||||||
| Operating Temp.(℃) | -20~+55 | -20~+55 | -20~+55 | ||||||
| Application | For Indoor or Outdoor Use | For Indoor or Outdoor Use | For Indoor or Outdoor Use | ||||||
| Finish | Black Plated | Black Plated | Black Plated | ||||||
SKU: ET-SP2W-DFS
Data sheet
- Type
- Power Splitter
- Connector Type
- Din
- Frequency
- 698-2700MHz
- Colour
- Grey Or Customized
- SKU
- ET-SP2W-DFS
- Brand Name
- Eteily
- Operating Temperature
- -20~+55℃
